dos feed C
material feeding system/cartridge holder
dos feed C
material feeding system/cartridge holder
material feeding from cartridges for small series.
The dos feed C is a material feeding unit that reliably transports viscous media with a viscosity of over 70,000 mPa•s, using compressed air, from cartridges to the dispenser. It is ideal for applications with low material consumption and can be used for Semco cartridges, for example.
The dos feed C designed by dosmatix, is characterized, like all dosmatix products, by its modular design. It can accommodate cartridge sizes of 6 and 20 ounces and impresses with its innovative bayonet closure, which makes it especially user-friendly to handle.
Practical and user-friendly.
any questions about the product? contact us:
this is why dos feed C
is the right product for you
this is why dos feed C is the right product for you
Weight-optimized for precise potting results
- Lightweight design for maximum dispensing speed
- Space-saving, slim design
User friendly
handling
- Easy cartridge replacement
- Level indication over the entire cartridge range
Variable sizes for common cartridge types
- Available in two versions 6 and 20 oz
- Compatible with manufacturers such as Semco or Euro cartridges
technical data
| Variant | dos feed C S (6oz.) | dos feed C M (20oz.) | dos feed C Euro |
| Compatible cartridges | Semco (others on request) | Semco (others on request) | 310 ml external thread (standard EURO) 310 ml external thread (aluminium) 310 ml internal thread |
| Feed volume | 180 ml | 600 ml | 310 ml |
| Weight | ca. 1.6 kg | ca. 2.1 kg | ca. 1.85 |
| Max. height cartridge holder | 485 mm | 620 mm | 593 mm |
| Max. height with angle adapter | 555 mm | 690 mm | 663 mm |
| Cartridge diameter | 45 mm | 73.5 mm | 51.5 mm |
how dos feed C works
Fixing the dos feed C cartridge holder to the dispenser.
Unscrewing/screwing on the cartridge holder.
Placing of the material cartridges into the dos feed C.
Feeding of the material by means of compressed air from the cartridge into the dispenser.
